MECHANICAL INSTALLATION
ACR7000 Controller Controller Installation Guide 15
Mounting Orientation
The ACR7000 should be mounted to a vertical surface in the orientation shown below to allow for vertical air
flow through the cooling vents on the top and bottom of the product
Consult factory to review applications where vertical mounting is not possible.
Note Inch (mm)
A -Top/Bottom
1.0 (25)
C - Sides
0.25 (6)
Figure 3. - Mounting Clearance
