ELECTRICAL INSTALLATION
ACR7000 Controller Controller Installation Guide 33
I/O Connector Pinout
Pin INPUTS (0-11)
INPUTS (24-31) /
OUTPUTS (32-35)
INPUTS (12-23)
INPUTS (72-79) /
OUTPUTS (36-39)
25 Input 5- Trigger Input 29- Input 17- Trigger Input 77-
24 Input 0- Trigger Input 24- Input 12- Trigger Input 72-
23 Input 0+ Trigger Input 24+ Input 12+ Trigger Input 72+
22 Input 1- Trigger Input 25- Input 13- Trigger Input 73-
21 Input 1+ Trigger Input 25+ Input 13+ Trigger Input 73+
20 Input 2- Trigger Input 26- Input 14- Trigger Input 74-
19 Input 2+ Trigger Input 26+ Input 14+ Trigger Input 74+
18 Input 3- Trigger Input 27- Input 15- Trigger Input 75-
17 Input 3+ Trigger Input 27+ Input 15+ Trigger Input 75+
16 Input 4- Trigger Input 28- Input 16- Trigger Input 76-
15 Input 4+ Trigger Input 28+ Input 16+ Trigger Input 76+
14 No connect No connect No connect No connect
13 Input 5+ Trigger Input 29+ Input 17+ Trigger Input 77+
12 Input 6- Trigger Input 30- Input 18- Trigger Input 78-
11 Input 6+ Trigger Input 30+ Input 18+ Trigger Input 78+
10 Input 7- Trigger Input 31- Input 19- Trigger Input 79-
9 Input 7+ Trigger Input 31+ Input 19+ Trigger Input 79+
8 Input 8- Output 32- Input 20- Output 36-
7 Input 8+ Output 32+ Input 20+ Output 36+
6 Input 9- Output 33- Input 21- Output 37-
5 Input 9+ Output 33+ Input 21+ Output 37+
4 Input 10- Output 34- Input 22- Output 38-
3 Input 10+ Output 34+ Input 22+ Output 38+
2 Input 11- Output 35- Input 23- Output 39-
1 Input 11+ Output 35+ Input 23+ Output 39+
