MECHANICAL INSTALLATION
16 ACR7000 Controller Installation Guide
Weight
The following table lists the weight of each controller model.
Controller Weights
Model
Weight
pounds (kg)
ACR74C
1.9 (0.9)
ACR78C 2.7 (1.2)
Mounting Guidelines
The ACR7000C Controllers are vented products. To prevent material spilling into the controller, mount it under
an overhang or in a suitable enclosure and mounted to a metallic, grounded (RF fashion) mounting plate is required
to meet the EMC performance required by IEC 61800-3.
ACR7000C products are made available under “Restricted Distribution” for use in the “Second Environment” as
described in the publication EN 61800-3 ed2.0.
Cable Routing
Route high power cables (motor and mains) at right angles to low power cables (communications and
inputs/outputs). Never route high and low power cables parallel to each other.
