ELECTRICAL INSTALLATION
26 IPA Hardware Installation Guide
System Installation Overview
This section details the components and configuration necessary for electrical installation of all models of the IPA.
Installation of a motion control system requires an IPA, a compatible motor (listed on page 17), and access to a
computer. Refer to the following figure for a diagram of this system.
Figure 3. - System Installation Overview
Warning: This product has been developed for industrial environments. Due to
exposed high voltage terminals, this product must not be accessible to
users while under normal operation.
IMPORTANT: An R-clamp must be connected to the drive and snugly attached to the
exposed braided shield of the motor cable in order to control electrical
noise.
