ELECTRICAL INSTALLATION
IPA Hardware Installation Guide 43
Power Supply
IMPORTANT: Power to the IPA can be supplied in multiple ways. Completely read
this section and comply with all safety measures before proceeding
with connecting the unit to power.
Input Power
The mains Motor Power supply and the optional Control Power supply for the drive/controller must meet the
requirements listed in the following table.
Input Power Requirement
Input Power
Requirements
Motor Input Power (L1, L2)
120/240 VAC, 50/60 Hz, single phase
Control Input Power (C1, C2)
120/240 VAC, single phase
Fuse Requirements
IPAs have no user-serviceable internal fuses. For safety, the user must provide a fuse in each of the mains input
lines.
Motor Power Fuse Information
Select the proper Motor Power input fuse for your specific application using the following table.
Motor Power Fuse Information
Drive
AC Voltage
Fuse Style
Rating
Fuse Type
IPA04
120 VAC
125 VAC Time Delay
20A
RK5 or better
240 VAC
250 VAC Time Delay
20A
RK5 or better
IPA15
120 VAC
125 VAC Time Delay
30A
RK5 or better
240 VAC
250 VAC Time Delay
30A
RK5 or better
The following table lists part numbers (at time of publication) for suitable fuses from several manufacturers. These
fuses are type RK5 (time delay fuses).
Fuse Part Numbers
Amps
Bussmann
Ferraz Shawmut (formerly Gould)
Littelfuse
10
FRN-R-10
TR10R
FLNR10
20
FRN-R-20
TR20R
FLNR20
30
FRN-R-30
TR30R
FLNR30
40
FRN-R-40
TR40R
FLNR40
