PCME STACK 990 User Manual

- PCME STACK 990 MANUAL: 11 -
Inputs
1 input for plant off indication, bag
cleaning reference and multiple
calibrations
4 inputs for plant off indication, bag
cleaning reference and multiple
calibrations
Enclosure Size
(LxHxD)
220 x 123 x 80 mm 263 x 160 x91 mm
Power Supply 90 to 260 VAC (50/60Hz), 1A 90 to 260 VAC (50/60Hz), 1A
System Options
4-core Cable Specify length required (10m per sensor included as standard)
Spur Divides cable into 2 branches
Power supply / repeater
Voltage and signal boost for extended cabling runs with
multiple sensors
Analogue input module (AIM)
4 x 4-20mA inputs
4 x Digital inputs
Analogue output module (AOM) 8 x 4-20mA (500 Ohm)
Alarm output module (ROM) 8 x Relay (1A @ 250V)
Isolating Spur Provides Surge protection
