PENKO SGM710 - Appendix I

Appendix I
SGM700 Digitizer
103
Description Definition
Weight filtered net weigher value that can react on mulit range/interval
Fast Gross unfiltered gross weigher value
Fast Net unfiltered net weigher value
Display Gross filtered gross weigher value
Display Net filtered net weigher value
Tare tare value
Peak highest reached weigher value can be reset by button peak reset
Valley lowest reached weigher value can be reset by button valley reset
Hold Stored hold value
Weight x 10
filtered net weigher value shown with extra decimal that can react
on multi range / multi interval
Fast Gross x 10 unfiltered gross weigher value shown with extra decimal
Fast Net x 10 unfiltered bet weigher value shown with extra decimal
Display
Gross x 10
filtered gross weigher value shown with extra decimal
Display
Net x 10
filtered net weigher value shown with extra decimal
Tare x 10 tare value shown with extra decimal
Peak x 10
highest reached weigher value shown with extra decimal can be
reset by button peak reset
Valley x 10
lowest reached weigher value shown with extra decimal can be
reset by button valley reset
Hold x10 Stored hold value shown with extra decimal
Signal mV signal from the load cell(s)
