SGM700 Digitizer
Configuration Menu -PCL-
Use key 1 and 2 to change the value. Key 1 is for changing the number
(1-9), key 2 is for changing the position of the cursor. Confirm by pressing
key 3 for >2 sec.
Up Down
Left Right Confirm
The following screen is visible:
6.14 - - - PCL Pre-calibration settings
In this menu, the Pre-calibration settings can be set. Options are:
Press key 2 <2 sec to enter the pre-calibration settings.
The following screen is visible:
76
Pcl 1 Polarity of input range
PcL 2 Amplier sensivity
PcL 3 Input oset
PcL 4 Recall pre-calibraon
To Next Page
