SGM700 Digitizer
1. Load cell / power connection
1.4 SGM730 digitizer CAN
9
Analoge output
(option)
Local bus
To PC
Config
software
DC POWER
SUPPLY
18-32Vdc
6-Wire load cell
connection
Vexc=5Vdc
Inputs
Input 1=5khz
18-28Vdc
Outputs
Max. 35V/0.5A
AC/DC
Remote
canbus
When the SGM700 is powered by USB
(not 24Vdc) the loadcell interface, the
analog output and CAN bus don
’t work.
This product is intended to be supplied by a Class 2 or
Limited Power Source, rate 18
- 32 Vdc, 0.2A@24Vdc.
