SGM700 Digitizer
1. Load cell / power connection
1.6 SGM750 digitizer Serial
11
Analoge output
(option)
Local bus
To PC
Config
software
DC POWER
SUPPLY
18-32Vdc
6-Wire load cell
connection
Vexc=5Vdc
Inputs
Input 1=5khz
18-28Vdc
Outputs
Max. 35V/0.5A
AC/DC
RS232/RS422
When the SGM700 is powered by USB
(not 24Vdc) the loadcell interface, the
analog output and Serial communicaon
don’t work.
This product is intended to be supplied by a Class 2 or
Limited Power Source, rate 18
- 32 Vdc, 0.2A@24Vdc.
