SGM700 Digitizer
1. Load cell / power connection
1.2 SGM710 digitizer analog
7
Analoge output
(option)
Local bus
To PC
Config
software
DC POWER
SUPPLY
18-32Vdc
6-Wire load cell
connection
Vexc=5Vdc
When the SGM700 is powered by USB
(not 24Vdc) the loadcell interface and
the analog output don
’t work.
This product is intended to be supplied by a Class 2 or
Limited Power Source, rate 18
- 32 Vdc, 0.2A@24Vdc.
