SGM700 Digitizer
4
TABLE OF CONTENT
Chapter Page
1. Loadcell power connection 6
1.1 SGM700 basic digitizer
6
1.2 SGM710 digitizer analog
7
1.3 SGM720 digitizer Ethernet
8
1.4 SGM730 digitizer CAN
9
1.5 SGM740 digitizer Profibus
10
1.6 SGM750 digitizer Serial
11
2.Indication of display 12
3. Explanation of front keys 13
4. First use of Indicator 14
4.1 Configuration menu structure 14
4.2 Weigher Setting 15
4.3 Calibration 17
4.4 First use by using PI Mach II software 21
5. Main Menu 29
5.1 Setpoints (not for SGM710)
29
5.2 TAC (Traceable Acces Code) 30
5.2 CAL (Calibration counter) 31
6. Configuration Menu 32
6.1 Setpoint function settings (not for SGM710)
33
6.2 Setpoint action settings (not for SGM710)
34
6.3 Analog output settings 36
6.4 Local bus communication settings (RS485) 40
6.5 Ethernet settings (SGM720 only) 41
6.6 Can bus port settings (SGM730 only) 47
6.7 Profibus settings (SGM740 only) 50
6.8 RS232 port settings (SGM750 only) 52
6.9 RS422 port settings (SGM750 only) 56
6.10 Indicator settings 60
6.11 Multi range/interval settings 67
6.12 Filter settings 70
6.13 Digital filter settings 74
6.14 Pre-calibration settings 76
6.15 Calibration settings 79
6.16 Theoretic calibration 84
