SGM700 Digitizer
Configuration Menu -rng- -continue-
In rng 3 you set the auto range reset option. Choose between:
oF: Multi Range = the highest shown step size will be reseted after the signal has
been lower or equal to zero
on: Mulit Interval = the highest shown step size will be reseted after the signal
reaches the previous range.
To change the auto range reset option press key 2 < 2 sec.
The following screen is vissable:
Use key 1 change the reset option. Confirm by
pressing key 3 for >2 sec.
Up Down Confirm
Configuration Menu -FIL-
6.12 - - FIL Filter settings
In this menu, the filter settings can be set. The display filter will damp the weigher
signal to the display to get a calm display view.
Options are:
Press key 2 <2 sec to enter the filter
settings.
70
FIL 1 Display lter band
FIL 2 Display lter factor
FIL 3 Zero suppressing
FIL 4 Shown indicator on display
