SGM700 Digitizer
First use of indicator -continue-
When the maximum net weight value is set succesfully, the following screen is
visible:
Dis- play step size
Press key 1 <2 sec. untill you see Ind 5 and press key 2 <2 sec.
Use Ind 5 to set the display step size. The step size
defines the scaled parts of the weight value. The display value will be rounded off
to the nearest value with a valid step size.
Use key 1 to select the correct step size.
Choose between 1, 2, 5, 10, 20, 50, 100, 200, 500 and confirm by pressing key 3
for >2 sec.
Up Down Confirm
Done succesfully, the following screen is visible:
Decimal point
To set the Decimal point position, enter Ind 6 by pressing key 2 <2 sec.
The following screen is visible:
16
