SGM700 Digitizer
Configuration Menu –Can- -continue-
In CAn 2 you set the Canbus address of the SGM730. Up to 8 devices can com-
municate with eachother, sharing inputs, outputs, markers and indicators. Press
key 2 <2 sec. to enter CAn 2. Set the address using key 1 and key 2 confirm by
pressing key 3 >2 sec. (options are: 1-8).
Increase Decrease Confirm
When confirmd the following screen will be vissable:
In CAn 3 you set the Canbus subaddress of the SGM730. When using a subad-
dress, up to 40 devices can communicate with each other. Press key 2 <2 sec. to
enter CAn 2. Set the address using key 1 and key 2 confirm by pressing key 3
>2 sec. (options are: 1-5).
Increase Decrease Confirm
When confirmd the following screen will be vissable:
48
