29
* Indicators 10 and 11 appear only for images taken with the flash.
* Indicators 17, 18, 19, and 20 appear only for images taken with the
corresponding functions enabled.
* Indicators 23 and 24 do not appear for RAW images.
A histogram shows the brightness
distribution of an image. The
horizontal axis indicates the
brightness (dark at the left and bright
at the right) and the vertical axis
indicates the corresponding number
of pixels.
The shape and distribution of the
histogram before and after shooting
tell you whether the exposure level
and contrast are correct or not, and let you decide if you need to adjust
the exposure and take a picture again.
Copyright Information Display
1
Captured image
5
Battery level (p.41)
2
Protect setting (p.135)
6
Photographer’s icon
3
Memory status (p.47)
7
Photographer (p.181)
4
Folder number-File number
(p.177)
8
Copyright Holder’s icon
9
Copyright Holder (p.181)
Using the Histogram
100-0001
100-0001
ABCDEFGHIJKLMNOP
ABCDEFGHIJKLMNOP
1234567890123456
1234567890123456
ABCDEFGHIJKLMNOP
ABCDEFGHIJKLMNOP
1234567890123456
1234567890123456
1 2 3 4
6
7
8
9
5
Number of pixels→
(Dark) ← Brightness → (Bright)
Underexposed
portions
Overexposed
portions

Pentax MX-1 Specifications

General

Aperture	f/1.8-2.5
ISO Range	100 - 12800
Image Stabilization	Sensor-shift Shake Reduction
Storage Media	SD/SDHC/SDXC memory card
Weight	391 g (including battery and memory card)
Effective Pixels	12.0 MP
Lens	28-112mm (4x Optical Zoom)
Shutter Speed	1/2000 to 30 sec
LCD Screen	3.0-inch tilting LCD, 920, 000 dots
Video Resolution	1920x1080 (Full HD)
Battery Type	Rechargeable D-LI106 lithium-ion battery
