34
B2 Assembly of Extensions
Additional levels
Warning
Risk of falling!
During the assembly work, keep the
hatch closed!
The number of additional levels is limit-
ed to a maximum of 5 floors.
Max. standing height ≤ 1060 cm.
Assembly
Assembly process is repeated accord-
ing to the steps on page 31 and 32.
Fig. B2.04
≤ 1060 cm
PERI UP Flex Reinforcement Scaffold 75 and 100
Instructions for Assembly and Use – Standard Configuration
