Peri UP Flex - C3 Reaction Forces

41
C3 Reaction forces
Scaffold width 75 cm (100 cm)
Standing
height
[cm]
Base width 150 cm
Assembly on UHV 150
Base width 250 cm
Assembly on UHV 250 / UVA 250
Standing
height
[cm]
Fi
[kN]
Fa
[kN]
Fi
[kN]
Fa
[kN]
224 – 260 5.1
(5.7)
2.2
(2.8)
5.1
(6.0)
1.9
(2.7)
224 – 260 /
248 – 280
424 – 460 7.3
(8.0)
3.7
(5.5)
8.0
(9.4)
3.0
(4.3)
424 – 460 /
448 – 480
624 – 660 8.6
(9.3)
4.9
(7.1)
9.3
(10.7)
3.6
(5.0)
624 – 660 /
648 – 680
10.6
(12.2)
4.4
(5.9)
824 – 860 /
848 – 880
12.1
(13.7)
5.2
(6.9)
1024 – 1060 /
1048 – 1080
Fig. C3.01
Table C3.01
Standing height
Scaffold width
Base width
F
i
F
a
PERI UP Flex Reinforcement Scaffold 75 and 100
Instructions for Assembly and Use – Standard Configuration
