Introduction
Intended use
The use in a way not intended accord-
ing to the Instructions for Assembly
and Use, or any use deviating from the
standard configuration or the intended
use represents a misapplication with a
potential safety risk, e.g. risk of falling.
Deviations from the standard configu-
ration must be verified for the applica-
tion by means of separate strength and
stability calculations. (Industrial Safety
Regulation Appendix 1, No. 3.2.1 and
explicitly reflected in the assembly in-
structions.)
In addition to original PERI UP Flex
scaffolding components, the following
original PERI UP scaffold components
are used for the assembly:
these must be marked with the corre-
sponding German approval numbers
– Z-8.1 – 957 for PERI UP Easy
– Z-8.22 – 863 for PERI UP Flex
as well as with the mark of conformity
<Ü>.
The use of other products and spare
parts is not allowed.
Changes to PERI components are not
permitted.
Instructions on use
System dimensions
System width: 75 cm and 100 cm
Storey height: 200 cm
Scaffold bay lengths:
150/200/250/300 cm
Max. height with:
base width 150 cm: H ≤ 660 cm
base width 250 cm: H ≤ 1080 cm
(H = underside of spindle up to level of
top deck)
Features
The system is based on PERI UP Flex
Modular Scaffold with supplementary
components.
Used as working scaffold in Load Class
1-3 according to EN 12811-1:
0.75 - 2.00 kN/m².
It fulfils wind load requirements ac-
cording to DIN EN 1004 and DIN EN
12811
– for free-standing scaffold according
to DIN EN 1004: q = 0.1 kN/m²
(v = 12.7 m/s),
– for scaffolds with base width 150 or
250 cm deviating from DIN EN 1004
in accordance with DIN EN 12811:
q = 0.2 kN/m² (v = 17.9 m/s),
– different assembly variations with up
to 3 bays in longitudinal direction.
Ballast is not required as long as the
scaffolding is positioned in front of a
wall or formwork and can be supported
by this. Units can be moved by crane
due to the extremely tight connections.
Product description
PERI products have been designed for
exclusive use in the industrial and com-
mercial sectors by qualified personnel
only.
These Instructions for Assembly and
Use are based on the Approval
“Z-8.22-863 PERI UP Flex Modular
System”.
They describe the standard configura-
tion for a reinforcement scaffold as
shoring for allowing temporary work to
be carried out on higher positioned
working areas.
PERI UP Flex Reinforcement Scaffold 75 and 100
Instructions for Assembly and Use – Standard Configuration
