Overview
Key
Pictogram | Definition
Danger / Warning / Caution
To be complied with
Information
Tip
Dimension specifications
Dimensions are usually given in cm.
Other measurement units, e.g. m, are
shown in the illustrations.
Conventions
Instructions are numbered with:
1. ....., 2. ....., 3. .....
The result of an instruction is shown
by:
Position numbers are clearly provid-
ed for the individual components and
are given in the drawing, e.g. 1, in
the text in brackets, for example (1).
Multiple position numbers, i.e. alter-
native components, are represented
with a slash: e.g. 1 / 2.
Presentational reference
The illustration on the front cover of
these instructions is understood to be
a system representation only. The as-
sembly steps presented in these In-
structions for Assembly and Use are
shown in the form of examples with
only one component size. They are
valid accordingly for all component siz-
es contained in the standard configura-
tion.
For a better understanding, detailed il-
lustrations are partly incomplete. Safe-
ty installations which have possibly not
been included in these detailed draw-
ings must nevertheless still be availa-
ble.
* if not identical to the action arrow.
Arrows
Arrow representing an action
Arrow representing a reaction
of an action*
Forces
Safety instruction categories
The safety instructions alert site per-
sonnel to the risks involved and provide
information on how to avoid these
risks. Safety instructions are featured
at the beginning of the section or
ahead of the instructions, and are high-
lighted as follows:
Danger
This sign indicates an extremely haz-
ardous situation which, if not avoided,
will result in death or serious injury.
Warning
This sign indicates a hazardous situa-
tion which, if not avoided, could result
in death or serious injury.
Caution
This sign indicates a hazardous situa-
tion which, if not avoided, could result
in minor or moderate injury.
Information
This sign indicates warning of situa-
tions whereby failure to observe the
information can result in material
damage.
Set-up of the safety instructions
Signal word
Type and source of the danger!
Consequences of non-compliance.
Avoidance measures
PERI UP Flex Reinforcement Scaffold 75 and 100
Instructions for Assembly and Use – Standard Configuration
