PERI UP Flex Reinforcement Scaffold 75 and 100
62
Item no. Weight kg
100014 2.470 Base Standard UVB 24
For assembly directly on the base spindle.
1
2
0
1
2
0
2
3
0
4
7
0
1
6
0
Ø11
48,3Ø
100863 1.020 Spindle Locking UJS
Secures the Adjustable Base Plates and Section
Spindles Ø 38 mm in the leg while moving.
Technical Data
Permissible load 1.5 kN.
138
7
0
6
7
SW 19
100411 3.390 Adj. Base Plate UJB 38-50/30 Note
With captive red Quick Jack Nut.
5
0
5
3 8Ø
100
150
Ø10
Ø17
3
5
5
m
in
4
5
m
a
x
3
0
100242 4.570 Adj. Base Plate UJB 38-80/55 Note
With captive yellow Quick Jack Nut.
5
9
5
m
in
4
5
m
a
x
8
0
5
100
150
3 8Ø
Ø10
Ø17
3
0
