PERI UP Flex Reinforcement Scaffold 75 and 100
73
Item no. Weight kg
111117 28.000 Staircase UAS 75 x 250/200, Alu
Assembly on Ledgers UH.
Technical Data
Permissible load 2.0 kN/m
2
.
35 0 / 600
2
0
0
0
2500 / 3000
100719 0.060 Bolt ISO 4014 M10 x 70-8.8 MU
As tension-proof connection of standards for sus-
pended scaffolds or lattice girders.
70
M10
SW 16
111053 0.059 Locking Pin Ø 48/57
As tension-proof connection of standards with a
diameter of 48 up to 57 mm.
Ø10
6
8
49 25
