13 - 48
1 102 Reversing OFF - ON OFF
113 Beep tone for section change OFF - ON OFF
114 Max. speed forwards at each OFF - ON OFF
pedal position
2 201 Machine configuration 1 - 2 1
1 = 3801-3/07, 3801-3/071
2 = 3801-11/071 (with tape feed)
202 Knee switch for section change OFF - ON OFF
(in the seam programs 3 -49)
203 Length of tape feed section (mm) 0 - 99 0
204 Length of prepared tape section (mm) 0 - 99 32
205 Tape speed during feeding 0 - 9 9
206 Tape speed during preparation 0 - 9 5
207 Tape speed during threading 0 - 9 0
208 Tape feed in knife 0.0 - 0.9 0.5
212 not speed variation with change of OFF - ON OFF
fullness
213 program interruption with pedal-position -2 OFF - ON OFF
3 301 Position 0 - 127 0
"Needle point at top edge needle plate"
302 Position "take-up lever t.d.c." 0 -127 107
303 Position "needle lowered" 0 -127 60
304 Reversing position 0 -127 107
305 Placement stitch position 0 - 127 7
4 401 Delay time "lift foot" (s) 0.01 - 1.50 0.02
402 Start delay after "lower foot" (s) 0.01 - 1.50 0.15
403 Thread trimming time (s) 0.01 - 0.20 0.12
404 Time for cleaning thread monitor (s) 0.01 - 1.50 0.25
13.08.03 List of parameters
The operator has free access to the "100" parameters. Parameters "200" – "800"
can only be changed after entering a code number and may only be changed by
authorised personnel.
Group Parameter Description Setting Set
range value
