Adjustment
13 - 28
Fig. 13 - 25
1
2
3
● Turn the handwheel until the point of the looper has reached the right hand side of the
needle.
● Move the carrier 1 (screw 2) according to the requirement.
The needle guard 3 must not press against the needle!
13.05.25 Clearance between the rear needle guard and the needle
Requirement
When the point of the looper, coming from the right hand side, has reached the right hand
side of the needle, the needle guard 3 must still be slightly touching the needle.
