Adjustment
13 - 52
E1 not assigned
E2 not assigned
E3 not assigned
E4 Start inhibitor
E5 not assigned
E6 Knee switch
E7 not assigned
E8 not assigned
E9 not assigned
E10 not assigned
E11 not assigned
E12 not assigned
E13 not assigned
E14 not assigned
E15 Light barrier tape feed (on 3801-11/071)
E16 Reference for fullness adjustment
13.11 Table of inputs
O1 Raise sewing foot (O1.1 and O1.2)
O2 Thread trimmer (O2.1 and O2.2)
O3 not assigned
O4 not assigned
O5 not assigned
O6 not assigned
O7 not assigned
O8 not assigned
O9 not assigned
O10 not assigned
O11 not assigned
O12 not assigned
O13 Tape cupping (on 3801-11/071)
O14 Blast air "front feed motion" (on 3801-11/071)
O15 Blast air "feed motion" (on 3801-11/071)
O16 Blast air "adjustment" (on 3801-11/071)
13.12 Table of outputs
