Adjustment
13 - 1
13 Adjustment
Please observe all notes from Chapter 1 Safety of the instruction manual! In
particular care must be taken to see that all protective devices are refitted
properly after adjustment, see Chapter 1.06 Danger warnings of the instruction
manual!
If not otherwise stated, the machine must be disconnected from the electrical
power supply.
13.01 Notes on adjustment
All following adjustments are based on a fully assembled machine and may only be carried
out by expert staff trained for this purpose.
Machine covers, which have to be removed and replaced to carry out checks and
adjustments, are not mentioned in the text.
The order of the following chapters corresponds to the most logical work sequence for
machines which have to be completely adjusted. If only specific individual work steps are
carried out, both the preceding and following chapters must be observed.
Screws, nuts indicated in brackets ( ) are fastenings for machine parts, which must be
loosened before adjustment and tightened again afterwards.
13.02 Tools, gauges and other accessories for adjusting
● 1 set of screwdrivers with blade widths from 2 to 10 mm
● 1 set of fork wrenches with jaw widths from 6 to 22 mm
● 1 set of Allan keys from 1.5 to 6 mm
● 1 brass drift, ø 6 - 8 mm
● 1 original Seeger pliers
● 1 pair of pincers, 90° offset
● 1 adjustable clamp, (Part No. 61-111 600-35)
● 1 metal rule, (Part No. 08-880 218-00)
● 1 adjustment pin, ø 5 mm (Part No. 13-030 341-05)
● 1 adjustment gauge (Part No. 61-111 642-19)
● 1 looper adjustment gauge (Part No. 61-111 643-06)
● Needles, system 4463-35
● Sewing thread and test material
● Spacing rings: 0.3/0.5/0.8 and 1.2 mm
13.03 Abbreviations
TDC = top dead center
BDC = bottom dead center
