Pfeiffer ASM 340 - Page 33

Advanced settings
33
SET POINTS
Selection Choice - Setting
limit
Initial settings
Audio Status Invalid / Valid Valid
Setting (If valid) 1 - 9 3
Digital voice Status Invalid / Valid Valid
Setting (If valid) 1 - 9 4
Pollution Status Invalid / Valid Invalid
Setting (If valid) 1·10
+19
- 1·10
-19
1·10
-05
Hard Vacuum Set
Points
Reject Point 1·10
+06
- 1·10
-13
1·10
-08
Reject Point 2 (If I/O 37 pins) 1·10
+19
- 1·10
-19
1·10
-07
Reject Point 3 (If I/O 37 pins) 1·10
+19
- 1·10
-19
1·10
-07
Reject Point 4 (If I/O 37 pins) 1·10
+19
- 1·10
-19
1·10
-07
Reject Point 5 (If I/O 37 pins) 1·10
+19
- 1·10
-19
1·10
-07
Sniffer set Points Reject Point 1·10
+06
- 1·10
-12
1·10
-04
Probe Clogged With Standard probe 1·10
+19
- 1·10
-19
1·10
-06
With Smart probe 0 - 9999 5
TEST
Selection Choice - Setting
limit
Initial settings
Method Hard Vacuum / Sniffer Hard Vacuum
HV Correction Status Invalid / Valid Invalid
Setting (If valid) 1·10
+20
- 1·10
-20
1·10
+0
Mode (If hard vacuum test method) Gross leak / Normal Normal
ProbeType (If sniffer test method) Standard / Smart Standard
Cycle End Automatic cycle end Operator /
Automatic
Operator
Setting
(If automatic)
Roughing Timer Status Invalid / Valid Valid
Setting 0 - 1 h 10 s
Test Timer 0 - 1 h 10 s
Inlet Vent Inlet Vent Operator /
Automatic
Operator
Delay 0 - 2 s 0 s
Vent Timer Status Invalid / Valid Invalid
Setting (If automatic) 0 - 1 h 9 s
Memo Function Active Non / Oui Non
Display Time Status Invalid / Valid Invalid
Setting (If automatic) 0 - 1 h 10 s
Zero activation Activation Operator /
Automatic
Operator
Zero Exit (if operator) Press once /
Press > 3 s
Press once
Value
(If automatic)
Trigger Timer / Set point Timer
Setting If Timer 0 - 1 h 10 s
If Set Point 1·10
+19
- 1·10
-19
5·10
-7
Bypass Option Mode None /
Quick Pump. /
Partial Flow
None
Evacuation delay Off / On Off
Regeneration Function launching - -
Massive Mode Active No / Yes Yes
Sensitivity High / Low High
