Diagnostic Software
EN 73DVDR70 & DVDR75/0x1 5.
Analogue Board (ANAB)
Example DS:> 1002
100200:
Test OK @
Nucleus Name DS_DCB_Keyboard
Nucleus Number 1004
Description Check all keys of the keyboard by confirming the key-code displayed of each key.
User Input None
Example DS:> 1004
100400:
Test OK @
Nucleus Name DS_DCB_RemoteControl
Nucleus Number 1005
Description Check the interface between the remote control and the DCB by checking the key-
code displayed
User Input None
Example DS:> 1005
100500:
Test OK @
Nucleus Name DS_DCB_Led
Nucleus Number 1006
Description Switch the record LED on, and after confirmation off.
The user confirms by pressing the REC key, STOP key, or the PLAY key on the local
keyboard. The PLAY key confirms that the LED is on and the REC key
User Input None
Example DS:> 1006
100600:
Test OK @
Nucleus Name DS_ANAB_CommunicationEcho
Nucleus Number 1100
Description Check the communication between the digital board and the analogue board by issu-
ing some echo string.
User Input None
Example DS:> 1100
110000: Hello Analogue Board
Test OK @
Nucleus Name DS_ANAB_CommunicationIicNvram
Nucleus Number 1101
Description Check the communication between the digital board and the NVRAM on the analogue
board.
User Input None
Example DS:> 1101
110100:
Test OK @
Nucleus Name DS_ANAB_CommunicationIicTuner
Nucleus Number 1102
Description Check the communication between the digital board and the tuner on the analogue
board
User Input None
Example DS:> 1102
110200:
Test OK @
Nucleus Name DS_ANAB_CommunicationIicDataSlicer
Nucleus Number 1103
Description Check the communication between the digital board and the data slicer on the ana-
logue board
User Input None
