Diagnostic Software
EN 77DVDR70 & DVDR75/0x1 5.
13 Input Signal is from Digital Board and it will be routed to the digital board.
14 No routing.
15 Input is Audio Signal from TUNER and it will be routed to Digital Board.
16 Input signal is AUDIO from dvio board and will be routed to Digital Board.
17 No routing.
18 No routing.
19 No routing.
20 Input signal is from REAR AUDIO IN 2 and will be routed to the digital board.
21 Input signal is from REAR AUDIO IN 1 and will be routed to the digital board.
22 Input signal is from REAR AUDIO IN 1 and will be routed to the digital board.
23 The Audio signal received from the Digital board will be outputted on Modulator channel 3.
24 The Audio signal received from the Digital board will be outputted on Modulator channel 4.
Nucleus Name DS_ANAB_SelectTunerChannel
Nucleus Number 1114
Description Set the tuner to receive a valid audio and video signal
User Input <Frequency*16> <video standard id>
Tuner frequency: to tune the tuner to e.g. 216 MHz, this parameter must be 3456.
(Since 216*16 = 3456. This is to avoid the decimal points to the parameter list.)
Video standard id: The table below shows which video standards are possible
Video standard id Europe NAFTA
16
32
48
64
80
96
112
PAL_BG NTSC
PAL_I Invalid
PAL_DK Invalid
SEC_L Invalid
SEC_LS Invalid
SEC_BG Invalid
SEC_DK Invalid
Example DS:> 1114 3456 16
111400:
Test OK @
Nucleus Name DS_ANAB_IICWriteRead
Nucleus Number 1115
Description Perform an IIC write and read action on the analogue board
User Input Writing:
[<W>|<w>] [I2C address] [number of data bytes to write]
with
<data[0]...data[n]> Max 16 data bytes (n < 16).
Reading:
[<R>|<r>] [I2C address] [number of data bytes to read]
Max 16 data bytes (n < 16).
Example DS:> 1115 w 0x94 2 0x06 0x02
111500:
Test OK @
Nucleus Name DS_ANAB_ClockAdjust
Nucleus Number 1116
Description Set the clock to the value passed through in the YYYY MM DD HH MM SS format
User Input <YYYY> <MM> <DD> <HH> <MM> <SS>
Example DS:> 1116 2002 11 11 11 11 11
111600:
Test OK @
Nucleus Name DS_ANAB_ClockReference
Nucleus Number 1117
Description Generate a 1 kHz signal on pin 7 (INT) of the clock IC
User Input None
Example DS:> 1117
111700:
Test OK @
Nucleus Name DS_ANAB_ClockCorrection
Nucleus Number 1118
