Diagnostic Software
EN 78 DVDR70 & DVDR75/0x15.
Frequency download string format
Description Store the clock IC correction value in NVRAM
User Input The correction value for the clock
Example DS:> 1118 1000023
111800:
Test OK @
Nucleus Name DS_ANAB_TunerAFCReferenceVoltage
Nucleus Number 1119
Description Store the reference voltage for the tuner in NVRAM
User Input The reference voltage, between 0 and 255
Example DS:> 1119 5
111900:
Test OK @
Nucleus Name DS_ANAB_TunerFrequencyDownload
Nucleus Number 1120
Description Store the frequency table in NVRAM. The frequency table is passed through the error-
string provided to the nucleus.
User Input See frequency table
Example DS:> 1120 2233 00 02 4E45442031
112000:
Test OK @
Format description remarks
X(XXX) Preset number
VVWW VV: Channel number
WW : Channel offset
ZZ Byte containing 8 bit fields for
TRUE/FALSE :
BIT 0: Decoder
BIT 1: Modulation
BIT 2: NICAM
SAP
BIT 3: Satpreset
BIT 4: Presetdefined
Channelpreferred
BIT 5: ExtPreset
BIT 6: NameManuallyChanged
BIT 7: ChannelPreset
NICAM/stereo bit for Europe
SAP/stereo bit for NAFTA
Preset defined bit is only used for Europe. For NAFTA, it is
renamed as channelpreferred to indicate if a channel is pre-
ferred or not.
TRUE if preset is defined from P50 as extern [TGA]
HH HfSystemFineTuning HfS: 4 bit, FT: -4,...,4
IIJJKKLLMM Netname Range: A,..,Z,0,..,9,_,.. Netname length exists for Europe
only.
‘II’ is the HEX-value for the first character, ‘JJ’ for the sec-
ond, Ö
The message string of (DS_MessageDef *msgString) should be in the format:
“X(XXX)_VVWW_ZZ_HH_IIJJKKLLMM”.
Here will be ‘X(XXX)’ a decimal value in the range of 0 to 255.
V, W, Z, H, I, J, K, L, M are hex values with out the prefix ‘0x’ (in the range 0... 9,A ... F)
“ _” Denotes a space character.
Remarks:
CHANNEL_SYSTEM is for NAFTA.
PRESET_SYSTEM is for Europe.
Nucleus Name DS_ANAB_StoreExternalPresets
Nucleus Number 1121
Description Store the external presets in NVRAM
User Input None
Example DS:> 1121
112100:
Test OK @
Nucleus Name DS_ANAB_BargraphLevelAdjust
Nucleus Number 1122
Description Measure the audio signal corresponding to 0dB per channel and store it as correction
value in NVRAM
