Diagnostic Software
EN 79DVDR70 & DVDR75/0x1 5.
System (SYS)
User Input none
Example DS:> 1122
112200:
Test OK @
Nucleus Name DS_SYS_HardwareVersionGet
Nucleus Number 1200
Description Get the hardware version and type of the digital board
User Input None
Example DS:> 1200
120000: Hardware ID = 00
The (PIO-pins) Digital Board ID = 2
Test OK @
DS:>
Nucleus Name DS_SYS_SoftwareVersionBootGet
Nucleus Number 1201
Description Get the version of the boot software on the digital board
User Input None
Example DS:> 1201
120100: Software Boot Version = 0001
Test OK @
Nucleus Name DS_SYS_SoftwareVersionDownloadGet
Nucleus Number 1202
Description Get the version of the download software on the digital board
User Input None
Example DS:> 1202
120200: Software Download Version = 0001
Test OK @
Nucleus Name DS_SYS_SoftwareVersionApplGet
Nucleus Number 1203
Description Get the version of the application software on the digital board
User Input None
Example DS:> 1203
120300: Software Application Version = 0001
Test OK @
Nucleus Name DS_SYS_SoftwareVersionDiagnosticsGet
Nucleus Number 1204
Description Get the version of the diagnostics software on the digital board
User Input None
Example DS:> 1204
120400: Software Diagnostics Version = 0001
Test OK @
120503 Something went wrong while transferring the data.
120504 User cancelled the upload.
Example DS:> 1205 1
120500:
Test OK @
Nucleus Name DS_SYS_EepromUpload
Nucleus Number 1205
Description Upload the contents of the NVRAM on the analogue board or the digital board to the
service PC, by using the X-modem protocol
User Input Choose one of the following parameters for the nucleus:
1. Upload the contents of the NVRAM of the digital board
2. Upload the contents of the NVRAM of the analogue board
Choose in the terminal on the control PC -> transfer -> receive file.
Select X-modem protocol. Then click receive in the dialogue and fill in the file name
in which you want to store the data.
