Diagnostic Software
EN 81DVDR70 & DVDR75/0x1 5.
Nucleus Name DS_SYS_VideoLoopThroughStart
Nucleus Number 1213
Description The video signal, which is confirm the user input, is routed from the input to the out-
put. Input is set with the routing nucleus 1112. All outputs are enabled.
User Input <vipInput> <VideoOutput> <VideoStandard>
1. vipInput (CVBS, YC, YUV, RGB).
2. VideoOutput (YUV, RGB).
3. VideoStandard (PAL, NTSC).
Example DS:> 1213 CVBS RGB PAL
121300:
Test OK @
Nucleus Name DS_SYS_VideoLoopThroughStop
Nucleus Number 1214
Description Stop routing the video input to all the outputs.
User Input -
Example DS:> 1214
121400:
Test OK @
Nucleus Name DS_SYS_VideoLoop
Nucleus Number 1215
Description Note: Before executing this nucleus the user must route the video signal on the an-
alog board with nucleus DS_ANAB_VideoRouting(1112 ).
User Input Video input of the digital board:
- CVBS
- YC
- YUV
- RGB
- TEST (The video output will be routed to the video input on the digital board.)
Video standard:
- PAL
- NTSC
When no input is given, the nucleus will take TEST for video input and PAL for video
standard.
Example DS:> 1215 cvbs ntsc
121500:
Test OK @
DS:> 1215 cvbs pal
121508: The VideoInputProcessor cannot detect a sync-signal.
Error @
DS:> 1215 yuv ntsc
121511:
Error in luminance signal(Y)
Error in chrominance signal(U)
Error in chrominance signal(V)
Error @
Nucleus Name DS_SYS_SlashVersionSet
Nucleus Number 1217
Description Set the slash version of the system
User Input The slash version
Example DS:> 1217 82
121700:
Test OK @
Nucleus Name DS_SYS_SlashVersionGet
Nucleus Number 1218
Description Get the slash version of the system
User Input None
Example DS:> 1218
121800: The slash version is: 82
Test OK @
Nucleus Name DS_SYS_Virginize
Nucleus Number 1219
