Philips IntelliVue TRx User Manual

Draft - 1 Aug 08
Technical Alarms (INOPs)
Alarms
5-13
ECG EQUIP MALF
ECG EQUIP MALF T
Source - Telemetry
Hard Failure of the ECG
equipment or failure to
calibrate ECG.
• Remove leadset.
Remove and re-insert
batteries. Let Self-
Test complete before
reinserting leadset.
• Replace the
transceiver.
• Contact Service.
ECG LEADS OFF
Note—This INOP may also
be configured to display as
a Red or Yellow Technical
Alarm.
Source - Telemetry
Red or
Yellow or
Hard
Technical
Alarm
• Multiple leads are
off.
• The short-range radio
connection between
the transceiver and
the MP5, MP2, or X2
Patient Monitor has
failed.
• Re-attach ECG leads
to patient.
• Identify and remove
the interference source.
• Reduce the number of
devices equipped with
short-range radio
capability.
<electrode> LEAD OFF
Source - Telemetry
Hard Single lead is off.
Note—If primary lead is
MCL, lead will be
identified as V/C in INOP
text.
Re-attach ECG lead to
patient.
INVALID LEADSET
Source - Telemetry
Hard • Wrong leadset.
• Leadset inserted
incorrectly.
• Bad lead selection
switches in the
transceiver.
• Check for appropriate
leadset.
• Check for correct
insertion.
• Contact Service.
LEADSET UNPLUGGED
Source - Telemetry
Hard Leadset has been
unplugged from the
transceiver.
Re-insert the leadset.
Technical Alarms (Inoperative Conditions)
Alarm Text Priority Condition What to do
