PIAGGIO MSS X9 EVOLUTION 250 - Refitting the flywheel magneto

- Apply the recommended product to the end of the screws.
Recommended products
Loctite 243 Medium strength threadlock
Loctite 243 medium-strength threadlock
- Fit the freewheel on the magneto flywheel making
sure that the ground side is in contact with the fly-
wheel itself, i.e. with wheel seeger ring visible.
- Lock the six clamping screws in criss-cross fash-
ion to the prescribed torque.
Locking torques (N*m)
Screw fixing freewheel to flywheel 13 ÷ 15
- Oil the free wheel "rollers".
Refitting the flywheel magneto
- Remove the freewheel retaining plate indicated
in the photograph
- Remove the transmission gear and the freewheel
MSS X9 Evolution 250 Engine
ENG - 105
