Ignition
IGNITION SECTION
Specification
Desc./Quantity
1 Pick - up
2 Magneto flywheel
3 Key switch contacts
4 Electronic controller
5 Spark plug
6 HV coil
7 Immobilizer aerial
8 Voltage regulator
9 Voltage regulator
10 Diagnostic tester outlet
11 Fuse 15A
12 Immobilizer LED
13 Battery 12V-12Ah
MSS X9 Evolution 250 Electrical system
ELE SYS - 55
