PIAGGIO MSS X9 EVOLUTION 250 - Headlight assy.

Headlight assy.
- Unscrew the 3 fixing screws;
- Disconnect the electric connectors;
- Extract the optical unit from the front.
Frame central cover
- Open the tank door;
- Remove the fuel tank cap and the protective rub-
ber
- Unscrew the 2 fixing screws located inside of it;
- Extract the centre cover in an upwards direction;
- Remove the tank door opening transmission.
Chassis MSS X9 Evolution 250
CHAS - 206
