PIAGGIO MSS X9 EVOLUTION 250 - Side Fairings; License Plate Holder

Side fairings
- After having removed the panel union element,
unscrew the rear screw of the lower panel;
- Unscrew the lower screw connecting to the spoil-
er;
- Extract the lower side panel by pulling it towards
the rear;
License plate holder
- Unscrew the 4 fixing screws on the rear frame;
- Disconnect the electric connector of the number
plate light;
- Remove the number plate bracket support with
the lamp socket.
N.B.
WHEN SECURING THE NUMBER PLATE BRACKET ON
THE SUPPORT, PAY ATTENTION TO INSERTING THE RIV-
ETS WITH THE HEAD ON THE WHEEL SIDE SO AS TO
PREVENT THE PROTRUDING PART OF THE RIVET FROM
INTERFERING WITH THE TYRE WHEN THE VEHICLE IS IN
USE.
Chassis MSS X9 Evolution 250
CHAS - 208
