Specification Desc./Quantity
20 Digital instrument unit
21 Front headlight N° 2 position bulbs 12V - 5W, N° 1 dipped beam bulb
12V- 55W, N° 1 upper beam bulb 12V - 55W
22 Wheel RPM sensor
23 Front brake stop button
24 Engine stop switch
25 Front right direction indicator N° 1 bulb 12V - 10W
26 Connector fitting for saddle opening device
27 Fitting for accessories
28 Anti-theft alarm fitting
29 Start up button
30 Key switch
31 Immobilizer aerial
32 Radiatore electric fan motor
33 Thermal switch for electric fan
34 Electronic ignition
35 Fuel level sender
36 HV coil
37 Thermistor
38 Oil pressure sensor
39 Pick - up
40 Automatic starter
41 Magneto flywheel
42 Rear right headlight N° 1 bulb 12V - 55W for position light, N° 1 bulb 12V -
10W for flashing light
43 License plate light bulb Type: ALL GLASS
Power: 12V - 5W
Quantity: 1
44 Stop light N° 5 bulbs 12V-2.3W
45 Remote starter switch
46 Diodo
47 Battery 12V-12Ah
48 Fuse 15A
49 Fuse (Rear position light protection, number plate light,
front position light)
7.5A
50 Fuse 10 A
51 Rear fuse holder box
52 Helmet compartment lamp bulb 12V-5W
53 Helmet compartment lighting button
54 Socket for users 12V - 180W max
55 Starter motor
56 Rear left headlight N° 1 bulb 12V - 55W for position light, N° 1 bulb 12V -
10W for flashing light
57 Voltage regulator
58 Saddle opening button
59 Saddle opening actuator
60 Stand switch
61 Horn
Wiring colour chart:
B=White - Bl=Blue - G=Yellow - M=Brown - N=Black - BV=White-Green - GN=Yellow-Black - Gr=Grey
- Rs=Pink - R=Red - Vi=Purple - V=Green - VN=Green-Black - BN=White-Black - BBl=White-Blue -
GV=Yellow-Green - Ar=Orange - GrBl=Grey-Blue - GrN=Grey-Black - BR=White-Red - RN=Red-Black
- BlN=Blue-Black.
CAUTION
SHOULD ANY INTERVENTIONS TO THE ELECTRIC SYSTEM BE REQUIRED, MAKE SURE THAT
THE LEADS TO THE ELECTRONIC IGNITION DEVICE ARE PROPERLY CONNECTED ACCORD-
ING TO POLARITY AND TO THE LEAD COLOURS.
Conceptual diagrams
Electrical system MSS X9 Evolution 250
ELE SYS - 54
