Removal
Proceed as follows:
- remove the muffler and rear wheel, following the
instructions in the "Rear suspension" Chapter.
- remove the two screws indicated in the figure.
- remove the stop ring and withdraw the pin.
- slide the two pads down.
- fit the new pads and tighten the screws (1) so that
they fit in the pad centring holes.
CAUTION
The brake pads are asymmetrical and cannot be interchanged
A = shock absorber side
B = wheel side
CAUTION
PADS MUST BE REPLACED IF THE FRICTION MATERIAL
THICKNESS IS LESS THAN 1.5 MM.
Fill
Front
- Rest the scooter on its stand on level ground.
- Refill the brake circuit reservoir to the maximum
level with the recommended fluid;
- Connect the bleed fitting to the appropriate tool
pipe (Mityvac manual pump);
- Actuate the tool at the bleed fitting, at the same
time constantly top up the brake reservoir to pre-
vent air being drawn into the system, until no more
air escapes at the bleed fitting:
The operation is finished when only oil comes out
of the bleed screws;
- Close the bleed screw and tighten to the prescri-
bed torque.
N.B.
Braking system MSS X9 Evolution 250
BRAK SYS - 188
