PIAGGIO MSS X9 EVOLUTION 250 - Level Indicators and Enable Signals Section

Level indicators and enable signals section
LEVEL INDICATORS AND ENABLE SIGNALS
Specification
Desc./Quantity
1 Digitsl instrument
2 Analogue instrument unit
3 Thermistor
4 Outside temperature sensor
5 Wheel RPM sensor
6 Fuel level sender
7 Oil pressure sensor
8 "Reset" button
9 Emergency button
10 Fuse 10 A
11 Key switch contacts
12 Radiatore electric fan motor
13 Thermal switch for electric fan
14 Magneto flywheel
15 Voltage regulator
16 Fuse 15A
Electrical system MSS X9 Evolution 250
ELE SYS - 58
