- Remove the protection, the bracket and the start-
er acting on the screw shown in the figure.
- Remove the 2 screws and the starter support with
the gasket.
- Remove the clamp and cover with the airing filter
of the diaphragm chamber.
- Remove the 4 fixing screws shown in the figure
and the vacuum chamber cover.
WARNING
DURING THE REMOVAL OF THE CARBURETTOR COVER
TAKE SPECIAL CARE NOT TO RELEASE THE SPRING
ACCIDENTALLY.
