Remove the acceleration pump piston with the ring
nut, the hood, the O-Ring and the spring from the
tank as shown in the figure.
Adequately support the carburettor and using a
rod and hammer remove the float pin acting from
the throttle control side.
Remove the float and the plunger.
MSS X9 Evolution 250 Engine
ENG - 153
