- Unscrew and remove the 2 screws shown in the
figure
- Unscrew the 4 fixing screws with the washers lo-
cated under the rear-view mirrors and beneath the
front centre cover;
- Remove the lower fairing.
N.B.
BE SURE TO CORRECTLY INSERT THE SEALS IN THEIR
SEATS WHEN REASSEMBLING.
