- Remove the nut shown in the figure, then take
out the pin. The engine is now free.
- Carry out the removal operations but in reverse order, observing the prescribed tightening torques.
Locking torques (N*m)
Lower shock absorber clamp 33 ÷ 41 Engine-swinging arm bolt 33 ÷ 41
MSS X9 Evolution 250 Engine from vehicle
ENG VE - 79
