Pioneer MEP-7000 Service Manual

110
MEP-7000
1
2 3 4
A
B
C
D
E
F
1
2 3 4
1 1
C D
Rear view
Reverse the Drive, and disconnect the two
flexible cables.
Reverse the Drive again, and remove the four
DM screws.
2
3
Remove the four screws.
1
Remove the mecha plate.
2
2
2
2
3
1
4
Bottom view
SRV1 Assy
1
1
1
Unhook the four hooks.
5
Remove the Slot-in Mechanism Assy.
6
Disconnect the connector.
3
Disconnect the flexible cable.
4
SLMB1Assy
5
6
5
3
3
3
3
5
5
Slot-in Mechanism Section
3
Earth spring
Note of earth spring
• Be sure not to lose it.
• Be careful to the installation
places.
• Confirm it by viewing.
Earth spring
Mecha plate
Mecha plate
This boss is not installation position.
Short-circuit two positions of C and D soldering.
1
Slot-in Mechanism Assy
Note: After replacement, connect the flexible cable,
then remove the soldered joint (open).
Traverse Assy 03-S
4

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
