Error Rate Count
The error rate of a certain duration (approx. 20 sec for a CD or 10,000 blocks for a DVD) from the address being paused
can be measured. The result of measurement and OK/NG judgment are indicated on the center display.
DVD 3.0 × 10-3 or less
CD 3.0 × 10-3 or less
GGV1036 (DVD-T002) DVD-VIDEO DL pressed disc
STD-905 CD pressed disc
Eject
The loaded disc can be ejected. On the drive status display, [EJECT] is displayed.
Mode Change
If the MASTER TEMPO key is pressed during Player Operation mode, the MASTER TEMPO LED will light, playback will
stop, then Test Operation mode will be entered. On the drive status display, [TEST MODE] is displayed.
Test Operation Mode
Servo operations can be controlled in steps.
Servo All Off TIME
CD Select MEMORY
DVD Select CALL
Step command PITCH BEND +
Focus Jump Up LOOP IN
Focus Jump Down LOOP OUT
Slider Move Fwd SEARCH FWD
Slider Move Rev SEARCH REV
Lens up/down TEMPO
Mode Change (to Player Operation mode) MASTER TEMPO
Function Key operation
Test Operation mode
Load a disc and start playback by pressing the Play/Pause key. Press the Play/Pause key at the point where you wish to
start measurement. The unit enters Pause mode ([PAUSE] is displayed on the drive status display).
Press the CUE key to start error rate measurement.
How to Measure
If the result does not meet the following criteria, it will be judged as NG:
How to Judge
Note: The above criteria are supposed to be met when measurement is performed with a control disc at the factory.
Note: Start operations after disc loading is completed.
Note: Be careful when using commands in Test Operation mode, because inappropriate use of those commands
may damage the drives.
