User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
101
4.3.6 Port Error Disabled Configuration
This page provides to set port error disable function. The Port Error Disable Configuration screens in Figure 4-3-13 and Figure
4-3-14 appear.
Figure 4-3-13: Error Disabled Recovery Page Screenshot
The page includes the following fields:
Object Description
• Recovery Interval
The period (in seconds) for which a port will be kept disabled in the event of a port
error is detected (and the port action shuts down the port). Default is 300 seconds.
• BPDU Guard
Enable or disable the port error disabled function to check status by BPDU guard.
• Self Loop
Enable or disable the port error disabled function to check status by self loop.
• Broadcast Flood
Enable or disable the port error disabled function to check status by broadcast
flood.
• Unknown Multicast
Flood
Enable or disable the port error disabled function to check status by unknown
multicast flood.
• Unicast Flood
Enable or disable the port error disabled function to check status by unicast flood.
• ACL
Enable or disable the port error disabled function to check status by ACL.
• Port Security
Violation
Enable or disable the port error disabled function to check status by port security
violation.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
