Planet GS-4210-24T2S User Manual

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
194
4.7.4.2 MLD Static Group
The MLD Static Group configuration screens in Figure 4-7-25 and Figure 4-7-26 appear.
Figure 4-7-25: Add MLD Static Group Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Select VLAN ID for this drop down list.
• Group IP Address
The IP address for a specific multicast service.
• Member Ports
Select port number for this drop down list.
Button
: Click to add IGMP router port entry.
Figure 4-7-26: MLD Static Groups Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID.
• Group IPv6 Address
Display the current group IPv6 address.
• Member Ports
Display the current member ports.
• Modify
Click to edit parameter.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
