User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
383
4.15.5 RMON History
Configure RMON History table on this page. The RMON History screens in Figure 4-15-7 and Figure 4-15-8 appear.
Figure 4-15-7: RMON History Table Page Screenshot
The Page includes the following fields:
Object Description
• Select Index
Select index for this drop down list to create the new index or modify the index
• Index
Indicates the index of the history entry. The range is 1-65535.
• Sample Port
Select port from this drop down list
• Bucket Requested
Indicates the maximum data entries associated this History control entry stored in
RMON. The range is from 1 to 65535, default value is 50.
• Interval
Indicates the interval in seconds for sampling the history statistics data. The
range is from 1 to 3600, default value is 1800 seconds.
• Owner
Specify an owner for the history. The range is 1-31 charactors.
Button
: Click to apply changes.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
