User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
4.7.6 Multicast Throttling Setting
Multicast throttling sets a maximum number of multicast groups that a port can join at the same time. When the maximum
number of groups is reached on a port, the switch can take one of two actions; either “deny” or “replace”. If the action is set to
deny, any new multicast join reports will be dropped. If the action is set to replace, the switch randomly removes an existing
group and replaces it with the new multicast group.
Once you have configured multicast profiles, you can assign them to interfaces on the Managed Switch. Also you can set the
multicast throttling number to limit the number of multicast groups an interface can join at the same time. The MAX Group and
Information screens in Figure 4-7-35 and Figure 4-7-36 appear.
Figure 4-7-35: Max Groups and Action Setting Page Screenshot
The page includes the following fields:
Object Description
• IP Type
Select IPv4 or IPv6 for this drop down list.
• Port Select
Select port number for this drop down list.
• Max Groups
Sets the maximum number of multicast groups an interface can join at the same
time.
Range: 0-256;
Default: 256
• Action
Sets the action to take when the maximum number of multicast groups for the
interface has been exceeded.
(Default: Deny)
-Deny - The new multicast group join report is dropped.
-Replace - The new multicast group replaces an existing group.
Button
: Click to apply changes.
